Total Number of Pages: 598
Total Hours: 16

Description
The Creo Parametric 11.0: Design Documentation and Detailing guide is designed for all draftspersons who document designs using Creo Parametric. It focuses on how to use Creo Parametric to communicate design information from your part and assembly models.

This content was developed using Creo Parametric 11.0, Build 11.0.1.0.

Topics Covered
• View creation
• View manipulation
• Detailing a drawing
• Drawing notes
• Tolerances
• Assembly drawings
• Drawing tables
• 2D sketching
• Symbols

Prerequisites
• Access to the Creo Parametric 11.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of the Creo Parametric: Introduction to Solid Modeling guide or similar levels of prior experience using the Creo Parametric software.
